ATD’s 2 Step System™ manages livestock manures in a cost effective, efficient and environmentally friendly manner. The system captures and concentrates virtually all nutrients (solid, liquid and gas) daily for storage or sale above ground to reduce hauling costs significantly and optionally reduce daily water demand. By separating nutrition from hydration you will have more nutrients per tonne in lighter loads and irrigation quality water year-round to match your crop needs.

Step 1 – Reduce water usage by recycling and reduce the cost of moving solids to the field by taking the solids out at the barn and sending only water and TDS to storage. If you are using settling ponds and wish to prioritize water management let’s just look at Step 2.

Step 2- Increases water recycling, capturing and concentrating Dissolved Solids, Ammonia for distribution.

We capture virtually all suspended solids daily with our Press and Clarifier and store them above ground.  Solids will be compact, lighter, and cheaper to apply.  It runs unattended.

The solids-free effluent is recycled to collect manure again with the rest sent to the Lagoon where more may be added direct from your source.  The Lagoon holds dissolved solids but will now create less GHG’s, won’t need agitation or an annual pump-out.

• Solids weight and volume are reduced. Nutrients/tonne are increased five-fold.
• Daily solids separation reduces Phosphorus transfer to the liquid stream. Solids can be distributed more accurately to meet the Environmental Farm Plan.
• Soil compaction is reduced by lighter loads. Dryer solids can be applied with simple equipment to improve operational flexibility.
• Labour and fuel costs to distribute and apply solids are reduced.
• Barn air quality improved, Nitrogen saved, and struvite production is reduced.
• The Lagoon will hold a little more water with the solids removed and it can be enlarged to collect any newly available water.
• The Lagoon will no longer produce Carbon Dioxide or Methane, thereby eliminating a major source of farm emissions.
• Add Fresh Water equal to the recycled flush water direct to your Lagoon or reduce demand on your source.
• Reduce transportation costs of solids to and from hub digesters.
• Small footprint reduces installation costs.
• Readiness for Step 2 and the ability to operate with less water.

The Farm Rotary Press discharges 30% Dry Matter to a trailer for delivery to the Digester to be eventually discharged as digestate to the Hub Rotary Press. The Hub Rotary Press discharges 30% solids to a trailer to be returned to the dairy for storage above ground and the Press effluent goes to the Hub Clarifier and TDS concentrator to be discharged as concentrate to a tanker trailer to be returned to you for storage. The Concentrator’s clean water will dilute the next load at the digester.

Should water restrictions or water costs increase, install Step 2.

• Recycle more water and optionally improve it to drinking water standard.
• Capture and increase TDS and Ammonia for storage.
• This introduces new technologies to the farm with training to staff members to ensure minimum supervision needs are met.

• TDS and Ammonia capture and concentration in a liquid improves placement and timing accuracy, reduces application costs and increases sales value.
• Phosphorus will be concentrated in the solids, Potassium and Nitrogen will be in the liquid
• Reduces demand on aquifer significantly.
• Irrigation volume is increased if surface water can be captured off-season to supplement lagoon contents.
• Potential recovery of some investment by sale of recycled water to unlicensed neighbor.
• Cleaner barn air with ammonia captured.

• Every farm is a custom client. Our job is to bring the greatest benefits at the least cost with a team that won’t promise what they can’t deliver.
• Project Estimates will be based on the Confidential Farm Data you enter on our downloadable Farm Facts Questionnaire and farm visits to confirm layout and proposal details.
• We will integrate whatever is needed with whatever you already have.
